2.2 Connecting diagram TB 40-1 temperature monitor TW
The TB 40-1 temperature limiter can also be configured as temperature moni-
tor. The connection of the 2nd thermocouple is omitted (terminals 12 –13).
Relay contacts OUT1 and OUT2 can be configured as additional limit outputs
and connected according to the connecting diagram below.
Limit contact LC also is also connected according to the connecting diagram be-
low.
Electrical connections
TB40-1
7
Connecting diagram TB 40-1 temperature monitor TW
L
N
90...250V
24V AC/DC
mA
V*
di1
INP1
1
2
3
4
7
5
8
6
9
10
11
12
13
14
15
LC
OUT2
OUT1
Limit contact
Zusatzkontakte /
Additional contacts
