5 Parameter setting level
5.1 Parameter survey
PArA Parameter setting level
И
М
Lim Limit
value
functions
InP.1 Input
1
rnG LC
setting
range
End
LC InL.1 rnGL
L.2 OuL.1 rnGH
H.2 InH.1
HYS.2 OuH.1
L.3
tF.1
H.3
HYS.3
g
Adjustment:
w The parameters can be adjusted by means of keys ÈÌ
w Transition to the next parameter is by pressing key Ù
w After the last parameter of a group, donE is displayed, followed by
automatic change to the next group.
+
Return to the beginning of a group is by pressing the
Ù key for 3 sec.
5.2 Parameters
Lim
Name Value range Description Default
LC -1999...9999 LC limit 100
L.2 -1999...9999 Lower limit 2 OFF
H.2
-1999...9999 Upper limit 2 OFF
HYS.2
0...9999 Hysteresis limit 2 1
L.3
-1999...9999 Lower limit 3 OFF
H.3 -1999...9999 Upper limit 3 OFF
HYS.3 0...9999 Hysteresis limit 3 1
L.3, H.3, Hys.3 only available if Fcn.1= TW
InP.1
Name Value range Description Default
InL.1 -1999...9999 Input value for the lower scaling point 0
OuL.1 -1999...9999 Displayed value for the lower scaling point 0
InH.1 -1999...9999 Input value for the upper scaling point 20
OuH.1
-1999...9999 Displayed value for the upper scaling point 20
t.F1
-1999...9999 Filter time constant [s] 0,5
Parameter setting level
Parameter survey 18 TB40-1
