3
TABLE OF CONTENTS
SECTION 1 - GENERAL PAGE NUMBER
1.1 Product Description 5
SECTION 2 - INSTALLATION & WIRING
2.1 Installation & Wiring 7
2.2 Unpacking 7
2.3 Location 7
2.4 Mounting 7
2.5 Preparation for Wiring 8
2.6 Wiring Connections 13
SECTION 3 - CONFIGURATION
3.1 Configuration (Set Up) 18
3.2 Configuration/Jumper Positioning 19
3.3 Operation Summary 19
3.4 Start up Procedure 20
3.5 Front Panel Operation 21
SECTION 4 - SERVICE
4.1 Service 33
4.2 Changing Charts 33
4.3 Changing Pens 33
4.4 Calibration 34
4.5 Test Mode 39
4.6 Troubleshooting and Diagnostics 43
APPENDICES
A - Board Layouts
A-1 Processor Board 50
A-2 SPST Relay/SSR Driver Output Board 51
A-3 SPDT Relay/SSR Driver Output Board 52
A-4 Current Output Board 53
B - Glossary 54
C - Model Number Hardware Matrix Details 55
D - Specifications 56
E - Software Record/Reference Sheet 59
Warranty Inside back page
