4.3 Set-point processing
The set-point processing structure is shown in the following picture:
4.3.1 Set-point gradient / ramp
To prevent setpoint step changes, a maximum rate of change is adjustable for
parameter r setpoint r
r.SP. This gradient acts both in positive and negative
direction.
With parameter r.SP set to OFFas in the factory setting, the gradient is
switched off and setpoint changes are made directly.
Configuration level
Set-point processing 44 KS 90-1 / KS 92-1
0
Ü
Xeff
SP.2
SP.E
0/4...20 mA
Internal
set-point
*
Ö
SP.Hi
SP.Lo
r.SP
- LED
External
set-point
INP2
Limitation
Ramp
2. set-point
Effektive
set-point
Ü
+
8
The ramp starts at process value
with the following switchings:
- int / ext-setpoint switching
-
/ switching
- Manual-/ Automatic switching
- at power on
SP SP.2
Index:
Ь
*
Ц
: int/ext-setpoint switching
: configuration
:
/ switching
SP.Fn
SP SP.2
1200
1199
°C
°F
SP.2 SP.E
para
func
