3.7 Second PID parameter set
The process characteristic is frequently affected by various factors such as pro-
cess value, correcting variable and material differences.
To comply with these requirements, KS 9x-1 can be switched over between two
parameter sets.
Parameter sets
PArA and PAr.2 are provided for heating and cooling.
Dependent of configuration ( ConF/LOG/Pid.2), switch-over to the second pa-
rameter set ( ConF/LOG/Pid.2) is via one of digital inputs di1, di2, di3,
key è or interface (OPTION).
g
Self-tuning is always done using the active parameter set, i.e. the second
parameter set must be active for optimizing.
Operation
KS 90-1 / KS 92-1 25 Second PID parameter set
Formulas
K = Vmax *
Tu
controller behavior Pb1 [phy. units] td1 [s] ti1 [s]
With 2-point and 3-point
controllers, the cycle time
must be adjusted to
t1 / t2 £ 0,25 * Tu
PID 1,7 * K 2 * Tu 2 * Tu
PD 0,5 * K Tu OFF
PI 2,6 * K OFF 6 * Tu
P K OFF OFF
3-point-stepping 1,7 * K Tu 2 * Tu
Parameter adjustment effects
Parameter Control Line-out of
disturbances
Start-up behaviour
Pb1 higher increased damping slower line-out slower reduction of duty cycle
lower reduced damping faster line-out faster reduction of duty cycle
td1 higher reduced damping faster response to
disturbances
faster reduction of duty cycle
lower increased damping slower response to
disturbances
slower reduction of duty cycle
ti1 higher increased damping slower line-out slower reduction of duty cycle
lower reduced damping faster line-out faster reduction of duty cycle
