Instruction Manual

Alpha DO 500

7

2.4 Installation

2.4.1 Mechanical

Dimensions

ENT

ESC

2-wire Dissolved Oxygen Transmitter

Alpha DO 500

CAL

2.4.2 Wall

Mount

Pierce through holes at
both sides

1

1

Cover the catch slots at
both sides with overlays

2
