Instruction Manual
TN-100/ T-100
2
Figure 1: Parts of TN-100/T-100 Turbidimeter
1.2
Display
All the LCD segments and annunciators that can appear on the display are shown in
Figure 2. The display is used for reporting the turbidity reading and to provide guidance
for the operation of the instrument. In addition, the display has several other
annunciators that are used to communicate error messages and provide user
guidance.
Figure 2: Customized LCD with all annunciators
Sample Vial
Sample Well
Index Mark
Liquid Crystal Display
Keypad
CAL 13 CAL 24
mg/l
NTU
ppm
%pH
TAvg
14-segment Liquid Crystal Display
Battery Indicator
Calibration
Standards
Units of
Measurement
