26
PC CONNECTIONS
It is possible to connect either a single thermal cycler or a series of instruments to a computer. The
options are:
1. To connect a single thermal cycler to a computer part number FGEN232 is required which contains a
connecting cable, software disk and instructions.
2. To connect several units via a daisy chain to a single computer part number FTGEN485 is required
which contains an RS485 set. Included are the connector for the computer, 1m cable for connecting
the first instrument to the computer, software disk and instructions. For each unit in the chain a
connecting cable (Part number 6103557) is required.
Computer
Adapter (if necessary)
Computer connector/
RS485 converter Select “Daisy Chain” Select “Termination Box”
Cables
On each unit select RS485 (up position)
