SHIMPO FGS-200-PV - Manual (Page 30)

FGS-200PV
SPECIFICATIONS
Capacity 100 kgf (200 lbs.)
Reduction Ratio 1:20
Precision Ball Screw Pitch 4mm / 1 Rotation
Stroke 400 mm (15.7 inch)
Travel Speed 0.6 mm/min (0.02 inch/min) - 400 mm/min (15.7 inch/min)
Drive Systeem Servo Motor (Trapezoidal thread (pitch 4mm / 1 rotation)
Speed Setting Selectable Speed Knobs (Speed A and Speed B)
Display 5 digit LED
Cycle (max) 1 - 9,999 times
Analog Signal Output 5 mV/ mm max +/- 2 V (400 mm)
Emergency Switch Push/Twist and release emergency stop button
Operating Modes
MANU MANUAL - Operates to selectable force limits
JOG JOG - Operates while direction key is pressed
SING SINGLE - Operates one cycle between upper and lower force limits
CONT CONTINUOUS - Cycles test between upper and lower force limits.
PROG PROGRAM - Specific Program Tests (each can store 5 programs on each type)
TOP: Top Load test with threshold option
STD: Standard test with preload option
BREAK: Break point test with force drop detection
Communication Feature USB 1.1 communication from Test stand to PC
Force Gauge Compatibility FGV-X and DFS models (Made after 1991)
Communication Software Windows based program, virtual front panel compatible with Windows XP/2000
Alarm Overload protection for test stand motor (stops motor when overload condition occurs).
Work Space 200 mm (7.87 inch) X 280 mm (11.02 inch)
Operating Temperature 0 - 45 degrees Celcius (Non-condensing)
Power Supply 120 V AC
Weight 23 Kg
