SHIMPO FGS-200-PV User Manual
Page 15
Available Menu on the Main Window
• File - exits out the program
• Color Scheme - changes the color of the window and its peripherals
• Language – this will be a future update to reflect different language on the
main window. Current version English only
• Modes buttons are located on top of the window, selected mode is
highlighted in red (Screen above indicates that the software is in
Continuous mode).
• Status indicator and Status message indicates condition of
the set up
• Start and Stop button are available (depending on mode
selected)
• Tare function for zeroing out the force gauge and
initializing the test
• Set Home button for changing the position of the reference
point or HOME position.
• HOME button for immediate return to reference point.
