Dimensions and Specifications
KEY: in
(mm)
FGS 250PV PROGRAMMABLE MOTORIZED TEST STAND SPECIFICATION
MODEL: FGS-250PVL (low speed)
± 0.0006” (0.015 mm) at max. speed
Max. 0.015” (0.383 mm) at max. speed
0.033 (0.85 MM) at max capacity
120VAC, 60Hz
14.42” (366 mm) x 50.22” (1275 mm) x 20.52” (521 mm)
115.7 lb (52.5 kg) 115.7 lb (52.5 kg) 126.8 lb (57.5 kg)
Max. 0.065” (1.649 mm) at max. speed Max. 0.172” (4.355 mm) at max. speed
± 0.0016” (0.04 mm) at max. speed ± 0.0036” (0.092 mm) at max. speed
500lb (250kg, 2,500N)
.49” – 4.92”/min (12.5 – 125 mm/min) 1.97 – 19.70”/min (50 – 500 mm/min) 5.12 – 49.23”/min (130 – 1250 mm/min)
FGS-250PVM (standard speed) FGS-250pvh (high speed)
CAPACITY:
TRAVEL SPEED:
STROKE:
31.10” (790 mm)
DISPLAY:
OPERATING MODE:
COMMUNIICATION:
LIMIT SWITCH REPEATABILLITY:
ZEROING FEATURE REPEATABILITY:
DEFLECTION:
POWER:
WEIGHT:
DIMESIONS:
Four digit LED, 0.41” high (10.5 mm), test stand can change english to metric
MANU, JOG, SING, CONT, PROG
Sensor: FGV, FGV-H, DFS, DRI (Remote Load Cell) To PC: RS-232C (Baud rate: 9600bps, data length: 8bit: 1bit:, parity: none)
