12
Communication With External Devices (continued)
External Control Command Descriptions (continued)
! APF ____________________ Auto-Power-Off
APF # CR # = 0: none
3: 3 minutes
! EXS ________________________External Input Setting
EXS # CR # = Z: TARE
H: HOLD
N: NONE
! HLD _________________ HOLD Trigger Mode
HLD # CR # = E: EDGE
L: LEVEL
O: Open Contact
C: Closed Contact
! LoG __________________ Memory Mode Setting
LoG # CR # =S: Continuous
N: Standard
! PKF __________________ PEAK Fast Mode
PKF # CR # = 0: OFF
1: ON
! DAF __________________ Analog Output Setting
DAF # CR # = 0: 1 msec
1: Display update
! ADF __________________ Filter Setting
ADF # CR # = 0: None filter
1: Normal filter
2: High filter
! D, DATN, DATT, DATC, AB, BB, BC, BD _______Data
output request (8 commands)
D CR ....Output displayed DATA
DATN CR ....Output average mode DATA
DATT CR ....Output tension PEAK DATA
DATC CR ....Output compression PEAK DATA
AB CR ....Stop continuous data output
BB CR ....Continuous data output
BC CR ....Model name confirmation request
BD CR ....Unit's confirmation request
Typical
gauge
response
! LIST ____________ Gauge’s present state
LIST CR (Command from PC)
MDL DFS-100
UNITS lb
DSPM NORMAL
DSPT 0.125
PKFST ON
DAFST ON
ADFIL NONE
OFFT NONE
232C 4800 B8 S2
232C PN CR LF X OFF
CP ON
HLMT 50.00
LLMT - 10.00
ET HOLD
ET LEVEL OPEN
LOG CONTINUE
Gauge Response
OK ....Command accepted
ERRO ....Did not recognize command*
ERR1 ....Command cannot be processed*
ERR2 ....Wrong nomenclature, i.e N,S,C*
ERR3 ....Communications error*
ERR7 ....Memory unit error**
IN HOLD ....When in HOLD, certain commands
cannot be processed.
IN MEMORY ....When in continuous memory mode
or standard mode (active), certain
commands can be processed.
* Check command and resend
** See troubleshooting section
UNITS CHANGE DISABLE .... This output is transmitted
to PC when someone is trying to change UNITS while
memory is accepting DATA.
