10
Communication With External Devices (continued)
RS232
Depending upon the type of data collection device that is being used with the DFS, it may be necessary to adjust the
factory settings mentioned at the beginning of this manual. To adjust the RS232 output characteristics:
1. Select the RS232 output (following the above instructions) but do NOT press the MEMO SET button.
2. To set the baud rate, press the HI-LO button. The small display will indicate “bPS” and the main display will reflect
the current setting.
3. Each time the > button is pressed, the main display will scroll through “9600”, “4800”, “2400” and “1200”.
4. To set the data length, press the HI-LO button; “dAT” will appear on the small display while the main display will
indicate the current setting.
5. Each time the > button is pressed the main display will toggle between “8” and “7”.
6. To set the stop pulse, press the HI-LO button. The small display will indicate “STP” and the main display will reflect
the current setting.
7. Each time the > button is pressed, the main display will toggle between “1” and “2”.
8. To set the parity, press the HI-LO button; “PRT” will appear on the small display and the main display will reflect
the current setting.
9. Each time the > button is pressed, the main display will scroll through “nonE”, “Eun” (even), “odd” (odd).
10. To set the data end code, press the HI-LO button; the small display will indicate “dEL” and the main display will
reflect the current setting.
11. Each time the > button is pressed, the main display will toggle between “Cr” and “CrLF”.
12. To set the software flow control, press the HI-LO button. The small display will indicate “fLO” and the main
display will reflect the current setting.
13. Each time the > button is pressed, the main display will toggle between “on” and “oFF”.
14. After selecting the software flow control, press the MEMO SET button to store the RS232 characteristics and exit.
ON-DEMAND CONTINUOUS STANDARD
STATISTICS STATISTICS Units
Units Units Max
DATA DATA Max
MAX MAX MIN
MIN MIN MIN
AVG. PKC LAST
DEV PKT **END**
HLMT AVG
LLMT DEV
HLMT
LLMT
DATA
1 XXX
2 XXXX
DATA
3 XXXX 1 XXXX
2 XXXX
Memory Data Output
Data may be output from memory by first pressing the
RECALL button and then pressing the MEMO SET button.
The main display will briefly indicate “oUt” to confirm that
the data has been sent. The following chart indicates the
order of the data output depending upon which memory
mode was used:
Output Data Format
The following chart demonstrates the format of the data
as it is output through RS232:
1 2 3 4 5 6 7 8 9 10 11 12 13 14
S T A T I S T I C S CR LF
CR LF
U N I T S k g CR LF
D A T A 1 0 0 CR LF
M A X — 1 0 0 0 CR LF
M I N — 1 0 CR LF
P K C 0 CR LF
P K T — 1 1 0 0 CR LF
A V G — 9 1 2 CR LF
D E V 8 . 2 CR LF
H L M T — 1 0 0 0 CR LF
L L M T — 9 0 0 CR LF
CR LF
D A T A — 9 1 5 CR LF
1
2
L — 8 9 5 CR LF
9 9 H — 1 0 0 5 CR LF
1 0 0 9 9 0 CR LF
* * E N D * *
