Function (Fct.)
Input Range Description
1.3.0 CUR. OUTP. I This configures the current output.
These functions are independent
from what is displayed.
Select Off, Level,
Distance, Volume,
Interface Level*, Layer*,
Interface Distance*,
Interface Volume* or
Ullage Volume. 1.3.1 FUNCTION.I.1
Level
Assigns a measurement parameter to
analogue output number 1.
* These parameters are not displayed
in this sub-menu unless the
instrument is configured for interface
measurement.
Calibrate the gauge using Function
1.7.2 Strapping Table before selecting
“Volume” here.
Select 4-20 mA, 4-20 mA
with a 3.7 mA failsafe
output or 4-20mA with a
22mA failsafe output. 1.3.2 RANGE.I 1
4-20 mA, E=22mA
Sets the analogue output range.
Settings with fail-safes will send an
error message if an error occurs i.e.
the level is lost.
Enter value with regards
to measure method
selected in Fct.1.3.1 and
the units set in Fct. 1.2.5. 1.3.3 SCAL.I.1 MIN
(Scale I1 Minimum)
As per order or 0.0
Assigns a length or volume value to 4
mA.
Refer to section 3.4.3, Example
Procedure 4.
Enter value as in 1.3.3 1.3.4 SCAL.I.1 MAX
(Scale I1 Maximum)
Tank height or probe
length as given in order
Assigns a length or volume value to
20 mA.
Refer to section 3.4.3, Example
Procedure 4.
Select as in 1.3.1 1.3.5 FUNCTION.I.2*
Level
Same as Fct. 1.3.1, except this is for
the second current output, if ordered.
Select as in 1.3.2 1.3.6 RANGE.I 2*
4-20 mA
Same as Fct. 1.3.2, except this is for
the second current output, if ordered.
Enter value as in 1.3.3 1.3.7 SCAL.I.2 MIN*
As per order or 0.0
Same as Fct. 1.3.3, except this is for
the second current output, if ordered.
Enter value as in 1.3.4 1.3.8 SCAL.I.2 MAX*
As order or Tank Height
As per order or Tank Height Same
as Fct. 1.3.4, except this is for the
second current output, if ordered.
*Displayed when interface measurement is selected in the factory menu
