SERVICE
6
29
OPTISENS PAS 2000
www.krohne.com 11/2008 • MA PAS 2000 R04 en
There are two different ways of cleaning a sensor: The sensor can either be cleaned as a master
or as a slave. Both options are described in the following instructions.
Cleaning the sensor as a master (sensor has its own relay)
• Select the sensor in the main menu by using ↑ or ↓.
• Press ^ for approximately five seconds to enter the sensor menu.
• Use ↑ or ↓ to select Cleaning Cleaning Cleaning Cleaning and press ^.
• In the Cleaning Cleaning Cleaning Cleaning submenu, select Cleaner Cleaner Cleaner Cleaner and set it to Flush Flush Flush Flush.
• Then specify the cleaning interval in minutes (Interval min Interval min Interval min Interval min) and the flush time in seconds
(Lenght sec Lenght sec Lenght sec Lenght sec).
• Specify the relay to be used according to the wiring inside the MAC 080 converter. For
example, if the solenoid is wired to relay #1, set Relay Relay Relay Relay to #1 #1 #1 #1 for flushing.
• For sensors configured as masters, Next time Next time Next time Next time displays the next time flush will be activated.
Pushing ^ will set it to current time and thus start cleaning.
• If needed, specify the extra freeze time in seconds (Freeze sec Freeze sec Freeze sec Freeze sec).
Figure 6-1: Flushing system
1 Flush nozzle for automatic cleaning
NOTE!
In order to clean the sensor, flushing must be activated in the Settings
Settings Settings Settings menu in the MAC 080
converter
