Event controls Event controls Event controls Event controls
The control boxes, at the left side of the event view, offer the possibility to scroll through the
recorded event data.
Symbol Description
Help Help Help Help
Calls up the online help.
Configuration dialog Configuration dialog Configuration dialog Configuration dialog
Opens the configuration dialog, in which you can change the properties of the function.
Message list Message list Message list Message list
Shows the actual event list.
Short-term archive list Short-term archive list Short-term archive list Short-term archive list
Shows the messages stored in the short-term archive.
Long-term archive list Long-term archive list Long-term archive list Long-term archive list
Shows the messages stored in the long-term archive.
Print Print Print Print
Current view will be printed, if a printer is connected and configured.
Export data Export data Export data Export data
Dialogue box for export of the actual event to a file.
Settings: Settings: Settings: Settings:
• File name and directory: File name and directory: File name and directory: File name and directory: Select the file name and the folder where the exported data
should be stored.
• Scope of data export: Scope of data export: Scope of data export: Scope of data export: Selection between two options for data export.
0 - All (all data in the event list window will be exported)
1 - Selection (only the selected view will be exported)
• Format: Format: Format: Format: Only "CSV" available as file extension. Clicking on the right box enables to set a
delimiter symbol for the data export.
Autoscroll Autoscroll Autoscroll Autoscroll
If selected, the event list will automatically insert new events at the beginning of the list
and will scroll down, so at any time the actual events are visible.
First message First message First message First message
List will be scrolled to the newest incoming message.
Previous message Previous message Previous message Previous message
Depending on the current selected message the previous message will be selected.
Next message Next message Next message Next message
Depending on the current selected message the next message will be selected.
Last message Last message Last message Last message
List will be scrolled to the latest upcoming message.
First page First page First page First page
List will be scrolled to the first page of the long-term archive. Only available if long-term
archive is selected.
