DEVICE DESCRIPTION
2
9
OPTITEMP TT 50 C/R
www.krohne.com 09/2010 - 4000636502 - MA OPTITEMP TT 50 C/R R03 en
Device description
2.1 Scope of delivery
The scope of delivery always consists of the transmitter and its documentation.
2.2 General description
The TT 50 transmitters are intelligent 2-wire universal transmitters with one channel.
The transmitters are intended for:
• Temperature measurements with resistance thermometers
• Temperature measurements with thermocouples
• Temperature difference measurements with resistance thermometers
• Measurements with potentiometers
• Voltage measurements in a range -10…+500 mV
The TT 50 C / TT 50 C Ex TT 50 C / TT 50 C Ex TT 50 C / TT 50 C Ex TT 50 C / TT 50 C Ex are designed for installation in a "B connection head" according to
DIN 43729 or larger.
The TT 50 R TT 50 R TT 50 R TT 50 R is designed for installation on a rail according to DIN 50022.
The 2-wire universal transmitters are HART ® 5-compatible. Configuration of the transmitter is
possible with:
• HART ® 5 protocol via 4…20 mA output circuit
• HART ® 5 hand held terminal
• The third part PC software with a FSK modem for HART ® 5 communication
• PC configuration software (HartSoft) with HART ® modem
To configure the transmitter using an IBM-compatible PC, the "HartSoft" software is required.
The Windows-based "HartSoft" software can be used to access all functions of the transmitter. It
is also used for configuration, calibration, display and documentation.
INFORMATION!
The TT 50 C
TT 50 C TT 50 C TT 50 C is optionally available for operation in potentially explosive areas (zone 0, 1 and 2
and division 1 and 2).
