4. OPERATION
Figure 4 shows the location of all operating controls and input/output terminals followed by an expla-
nation of each. The unit is shipped with shorting links installed connecting the following terminals:
+RC to –RC and REF to RV
Withstanding voltage : (at 15-35°C
ambient, 10-85% relative humidity) 2000Va-c for 1 minute. Cutout current is 20mA Between input and ground
500Va-c for 1 minute. Cutout current is 100mA Between output and ground
3000Va-c for 1 minute. Cutout current is 20mA Between input and output terminal
Insulation Resistance: (at 25°C,
65% relative humidity) 100 Megohms minimum (500Vdc) Between output and ground, input and
ground, and input and output,
Humidity: 10% to 95% relative humidity, noncondensing,
Wet Bulb temperature
operating and non-operating
Vibration: 5-10 Hz., 10mm amplitude, 10-200 Hz., acceler-
ation 64.3ft./s
2 (19.6M/s 2 ) (2g)
non-operating 1 hr. on each of 3 axes,
sweep time 10 minutes
Shock: Acceleration: 964.6ft./s 2 (294M/s 2 ) (30g),
Pulse Duration: 11ms ± 5 msec
(non-operating, 1/2 sine pulse, three
shocks on each axis, Power Supply is
fixed on its bottom side)
Safety: Approved by UL60950-1, CSA 22.2 No. 60950-1 (C-UL), and EN60950-1:2001 +A11 (TÜV),
complying with Electrical Appliance and Materials Safety Laws (meeting the regulations of
creepage surface and spacial distance in item 8 of the Appendix). RKE 1500W units are CE
marked per the Low Voltage Directive (LVD), 73/23/EEC and 93/68/EEC. [The standards do
not apply with DC input operation]
EMC Emission - Conducted: Complies with FCC Class B, VCCI-Class B, EN55011-B, EN55022-B
EMC Emission - Radiated: Complies with FCC Class B, VCCI-Class B, EN55011-B, EN55022-B
EMC Emission - Input harmonics
current: Complies with EN61000-3-2
EMC Immunity Complies with EN50082-2
EMC Radiated susceptibility: Complies with EN61000-4-3 level 3 normal operation
EMC Conducted susceptibility: Complies with EN61000-4-6 level 3 normal operation
ESD: Complies with EN61000-4-2, level 4 normal operation
Electrical fast transient burst: Complies with EN61000-4-4 level 3 normal operation
Surge withstand: Complies with EN61000-4-5, level 4 No damage
Power Frequency Magnetic Field: Complies with EN61000-4-8, level 4 normal operation
Voltage dips interruptions and
variations Complies with EN61000-4-11 normal operation
Dimensions: 3.62 in. (92 mm) x 4.72 in. (120 mm) x 9.33 in. (237 mm)
Mounting: Four No. M4 tapped holes on the sides and the bottom
Maximum Screw Penetration: 0.24 in. (6 mm)
Cooling: Forced air flow - fan
Frame Material/Cover Material: Steel
Weight 6.61 lbs, 3.0Kgs. maximum
TABLE 2. POWER SUPPLY RATINGS AND SPECIFICATIONS (CONTINUED)
CHARACTERISTIC SPECIFICATION CONDITION/NOTES
