Set Parameter Units and Sentinel Values
You can set sentinel values and set units for parameters by selecting a parameter and
clicking the Setup Sensor button.
Screen Element Purpose
Parameter
This menu lists the parameters that are available for the
selected sensor.
Units
This drop-down list allows you to select units for the
parameter you selected.
Sentinel Offline
Value
This is a text field in which you can enter the value that
you want to see in the data when a sensor is unable to
communicate. After you have entered a value, click the
Set button to save it.
Configure
This button becomes active when you select a parameter
that includes additional configuration options. Click the
Configure button to view the additional options.
Check mark
Clicking the Check mark saves the changes you have
made in this screen.
