ELECTRICAL SAFETY TESTER

USER MANUAL

1

1. PRODUCT INTRODUCTION

1-1. Description

The GPT/GPI-800 Electrical Safety Testers (EST) are designed for

AD/DC Withstanding Voltage test and Insulation Resistance test (IR) in

order to provide a safe and accurate test environment for the operator.

With thoughtful design described in 1-2. Feature insures a safe operation

environment of high voltage test to protect user from hazardous impact.

The Electrical Safety Testers comply with the requirement of the

electrical equipment & appliance control ordinances and JIS, CSA, UL,

BS and other overseas standards as well. The testers can be used for

withstanding voltage test of the various types of electrical and equipment

and components.

The GPT/GPI-800 series are based on the family of GW

withstanding voltage tester including AC Withstanding Voltage test, DC

Withstanding Voltage test and Insulation Resistance test. Please refer to

the table as follows:

Function

Model

AC

DC

IR

GPT-805 (500VA)

ˇ

GPT-815 (500VA)

ˇ

ˇ

GPI-825 (500VA)

ˇ

ˇ

GPI-826 (100VA)

ˇ

ˇ

ELECTRICAL SAFETY TESTER

USER MANUAL

2

1-2. Features

The GPT/GPI-800 series offer several other features:

1) Current and output voltage setting

A safe way to set the current and output voltage without high

voltage activated.

2) Easily and quickly setting with front panel control

A user-friendly interface provides user an easy and quick way to

set all parameters.

3) Testing time

Use micro processor to control testing time.

4) Adjustable ARC detect level

The ARC detect level can be adjusted with front panel control.

5) Adjustable output voltage during test

The output voltage can be adjusted during testing that add an

operation flexibility.

6) An alert indicator for high voltage

A flashing red LED indicates dangerous situation during high

voltage output is activated.

7) Remote I/O controller

In addition to the 9 pin remote I/O controller to control

START/RESET, it also provides PASS/FAIL/TEST signal for

professional use.
