FUNCTION GENERATOR
USER MANUAL
13
14. Sweep Time
Control and
LIN/LOG Selector
(1) Rotate the outer knob clockwise to adjust sweep time
for MAX, or invert for MIN.
(2) To proceed Linear sweep mode by pushing in the
knob, or select LOG sweep mode by pulling out the
knob.
14a. Sweep Rate
(Width) Control
Sweep width can be controlled from 0 to 1000 times.
15. INT/EXT Counter
Selector
Select internal counter mode (count the frequency of
model) or select EXT counter mode for an independent
counter (input signal from BNC
16 ).
16. EXT. Counter
Input Terminal
Accepts external signals for measurement.
17. TTL/CMOS
Output Terminal
TTL/CMOS compatible signal output
18. VCF IN/Sweep
Out Terminal
(1).Use to connect the input voltage required to perform
the “voltage control frequency” operation or the EXT
modulation operation.
(2).In Sweep mode, this terminal will output sweep
signal.
19. Main Output
Terminal
Main signal output.
20. Power Switch 115V and 230V selectable.
FUNCTION GENERATOR
USER MANUAL
14
5. USAGE DESCRIPTION
The function generator can provide versatile waveforms of high
efficiency and convenient operation. Familiarize yourselves with the
function thoroughly through Operation Manual and practice with all
accurate operation procedures can lead you to easily master the
performance of the Function Generator.
It is one of the best ways to observe waveforms by connecting the
instrument to Oscilloscope. Watch the effect in different control of
waveforms through Oscilloscope carefully when proceeding the following
steps:
5-1.First-step check:
(1) Ensure that the voltage of the main supply is compatible with this
instrument. The label on the rear panel states the required AC voltage.
(2) Connect the instrument to the main supply using the power cord
supplied.
(3) Press PWR switch 1 and ensure all the rotary controls are pushed in,
then rotate AMPL 12 knob to make the indication point up forward.
(4) Rotate the FREQ 13 control fully anticlockwise.
