FUNCTION GENERATOR
USER MANUAL
3
FOR UNITED KINGDOM ONLY
NOTE: This lead/appliance must only be wired by
competent persons
WARNING: THIS APPLIANCE MUST BE EARTHED
IMPORTANT: The wires in this lead are coloured in
accordance with the following code:
Green/ Yellow: Earth
Blue: Neutral
Brown: Live(Phase)
As the colours of the wires in main leads may not correspond
with the colours marking identified in your plug/appliance,
proceed as follows:
The wire which is coloured Green & Yellow must be
connected to the Earth terminal marked with the letter E or by
the earth symbol or coloured Green or Green & Yellow.
FUNCTION GENERATOR
USER MANUAL
4
The wire which is coloured Blue must be connected to the
terminal which is marked with the letter N or coloured Blue or
Black.
The wire which is coloured Brown must be connected to the
terminal marked with the letter L or P or coloured Brown or
Red.
If in doubt, consult the instructions provided with the
equipment or contact the supplier.
This cable/appliance should be protected by a suitably rated
and approved HBC mains fuse: refer to the rating information
on the equipment and/or user instructions for details. As a
guide, cable of 0.75mm² should be protected by a 3A or 5A
fuse. Larger conductors would normally require 13A types,
depending on the connection method used.
Any moulded mains connector that requires removal
/replacement must be destroyed by removal of any fuse &
fuse carrier and disposed of immediately, as a plug with
bared wires is hazardous if a engaged in live socket. Any re-
wiring must be carried out in accordance with the information
detailed on this label.
