FUNCTION GENERATOR
USER MANUAL
7
GFG-8210A
8. Sweep Operation
Sweep/Manual Switch selector
Sweep/Rate ＞100:1 ratio max. and adjustable
Sweep/Time 0.5Sec～30Sec adjustable
Sweep/Mode Lin./Log. switch selector
Sweep Out 0V~10±1V
9. Frequency Counter
Int./Ext. Switch selector
Range 0.1Hz～10MHz (5Hz~150MHz EXT)
Accuracy Time base accuracy ±1 count
Time Base ±20ppm (23℃±5℃) after 30 minutes warm up
Resolution
The maximum resolution is 100nHz for 1Hz and 1Hz for
100MHz.
Input Impedance 1MΩ/150nF
Sensitivity
≦35mVrms(5Hz~100MHz)
≦45mVrms(100MHz~150MHz)
10. General
Power Source AC115V, 230V±15% 50/60Hz
Operation
Environment
Indoor use, altitude up to 2000m.
Ambient Temperature 0℃ to 40℃.
Relative Humidity 80% (Maximum).
Installation category II
Pollution Degree 2
Storage temperature
& Humidity -10℃ to 70℃.
70% (Maximum).
Accessories
GTL-101 × 2
Instruction manual × 1
Dimension 251(W)×91(H)×291(D) m/m
Weigh Approx. 2.2 kg
FUNCTION GENERATOR
USER MANUAL
8
WARNING：To avoid electrical shock, the power cord
protective grounding conductor must be connected to
ground.
CAUTION：To avoid damaging the instrument, do not use
it in a place where ambient temperature exceeds 40℃.
CAUTION：To avoid damaging the instrument, do not
input more than DC15V to V.C.F.(V.C.G.).
CAUTION：To avoid damaging the instrument, do not
input more than AC150V to Frequency Counters
