FUNCTION GENERATOR
USER MANUAL
29
z FIGURE 11
FUNCTION GENERATOR
USER MANUAL
30
7. MAINTENANCE
The following instructions are used by qualified person only. To avoid
electrical shock, do not perform any service other than contained in the
operation instructions unless you are qualified to do so.
7-1.Fuse Rating and type
If the fuse blows, the FUNCTION GENERATOR will not operate.
Try to determine and correct the cause of the blown fuse, then replace the
fuse with the correct rating and type shown below:
FUSE Rating and Type Rating Input
MODEL
115V 230V Watts VA
GFG8210A T0.25A 250V T0.125A 250V 22 28
WARNING: For continued fire protection, replace only
with a 250V fuse of the specified type and rating, and
disconnect the power cord before proceeding fuse
replacement.
