ELECTRICAL SAFETY TESTER

USER MANUAL


39















The function key of front panel can not be used when any two pins
of the Reset、Start or Common function of remote control appear
short circuit. Please check the remote control device.

RESET (pin

1)

START

(pin 2)

COMMON (pin

3)

TESTING1 (pin 4)

TESTING2 (pin

5)

PASS1

(pin 6)

PASS2

(pin 7)

FAIL1

(pin 8)

FAIL2

(pin 9)

EST REMOTE

INTERFACE

REMOTE

CONTROLLER


ELECTRICAL SAFETY TESTER

USER MANUAL


40

6. MAINTENANCE

The following instructions are used by qualified person only to avoid

electrical shock, do not perform any service other than contained in the
operation instructions unless you are qualified to do so.

6-1. Fuse Rating and type

If the fuse blows, the product will not operate. Try to determine and

correct the cause of the blown fuse, then replace the fuse with
correct rating and type shown as below:

Line

voltage

Range

Fuse

Line voltage

Range

Fuse

100V
120V

90-110V

108-132V

T 7.0A

250V

220V
230V

198-242V
207-250V

T4A

250V

WARNING: For continued fire protection, replace

only with 250V fuse of the specified type and rating,

and disconnect the power cord before proceeding fuse

replacement.

6-2. Cleaning

To keep the instrument clean, wipe the case with a damp cloth and
detergent. Do not use abrasives or solvents.
