F a i l – GW Instek GPI-700A Series User Manual User Manual
Page 16
ELECTRICAL SAFETY TESTER
USER MANUAL
23
5. If you press RESET button the test will stop immediately.
6. If the result is pass, the PASS LED will be active.
RESET
S T O P
P A S S
ELECTRICAL SAFETY TESTER
USER MANUAL
24
7. If the result fails, the FAIL LED will be activated and the buzzer
will alarm operator. To stop the alarm, press RESET button again.
8. Use knob to view the result of group step by step.
RESET
F A I L
1 - 0 0
