Cv mode operating range, Cp mode operating range, Slew rate cc mode setting range – GW Instek PEL-3000 Series Quick Start Guide User Manual
Page 19: Slew rate cr mode setting range
CV Mode Operating Range
Model
PEL-3021
PEL-3041
PEL-3111
H Range
1.5V~150V
1.5V~150V
1.5V~150V
M Range
1.5V~15V
1.5V~15V
1.5V~15V
CP Mode Operating Range
Model
PEL-3021
PEL-3041
PEL-3111
H Range
17.5W ~175W 35W~350W
105W ~1050W
M Range
1.75W ~17.5W 3.5W~35W
10.5W ~105W
L Range
0.175W~1.75W 0.35W~3.5W 1.05W ~10.5W
Slew Rate CC Mode Setting Range
Model
PEL-3021
PEL-3041
PEL-3111
H Range
2.5mA/us
~2.5A/us
5mA/us
~5A/us
16mA/us
~16A/us
M Range
250uA/us
~250mA/us
500uA/us
~500mA/us
1.6mA/us
~1.6A/us
L Range
25uA/us
~25mA/us
50uA/us
~50mA/us
160uA/us
~160mA/us
Slew Rate CR Mode Setting Range
Model
PEL-3021
PEL-3041
PEL-3111
H Range
250uA/us
~250mA/us
500uA/us
~500mA/us
1.6mA/us
~1.6A/us
M Range
25uA/us
~25mA/us
50uA/us
~50mA/us
160uA/us
~160mA/us
L Range
2.5uA/us
~2.5mA/us
5uA/us
~5mA/us
16uA/us
~16mA/us
