S
PECIFICATIONS
The following are the basic specifications for the PEL-
3000 series. For detailed specifications, please see the
user manual
Rating
Model
PEL-3021 PEL-3041 PEL-3111
Operating
Voltage
1.5V~150V 1.5V~150V 1.5V~150V
Current 35A 70A 210A
Power 175W 350W 1050W
CC Mode Operating Range
Model
PEL-3021 PEL-3041 PEL-3111
H Range 0A~35A 0A~70A 0A~210A
M Range 0A~3.5A 0A~7A 0A~21A
L Range 0A~0.35A 0A~0.7A 0A~2.1A
CR Mode Operating Range
Model
PEL-3021 PEL-3041 PEL-3111
H Range 23.3336S
~400uS
(42.857mΩ
~2.5kΩ) 46.6672S
~800uS
(21.428mΩ
~1.25kΩ) 140.0016S
~2.4mS
(7.1427mΩ
~416.6667Ω)
M Range 2.33336S
~40uS
(428.566mΩ
~25kΩ) 4.6667S
~80uS
(214.28mΩ
~12.5kΩ) 14.0001S
~242.4uS
(71.427mΩ
~4.16667kΩ)
L Range 0.233336S
~4uS
(4.28566Ω
~250kΩ) 0.46667S
~8uS
(2.1428Ω
~125kΩ) 1.40001S
~24.24uS
(714.27mΩ
~41.6667kΩ)
