7.0
Specifications
Capacity
32 Input Devices
Power Input
N4X Input Voltage:
100-240VAC, 45-65Hz
11.5-30VDC
N7 Input Voltage: 11.5-30VDC
Power Consumption
Nominal:
.07 Watt @ 11.5VDC
Maximum: 1.2 Watts @ 11.5VDC (Includes Display w/Backlight and 4 LED’s active)
Display
1¼” x 6” Backlit LCD
RFI/EMI Protection
Complies with EN61326
Electrical Classification
NEMA 4X or NEMA 7
Dimensions
N4X Dimensions:
11.85”W x 13.73”H x 6.47”D
N7 Dimensions: 25”W x 15.5”H x 7.25”D (Full Assembly w/Mounting Plate)
Operating Temperature Range
-20°C to +70°C
Warranty
One year
