Page 97
Chapter 3
87
6. Lift the cover to expose the single securing screw. Remove the screw.
7. Lift the Fan module clear of the Mainboard.
Removing the CPU
1. Remove the CPU Fan Module. See “Removing the CPU Fan Module” on page 86.
Step
Size
Quantity
Screw Type
Mainboard
M2.5*6.5 (NL)
1
