58 Chapter 3
Removing the Hard Disk Drive2 Module
1. See “Removing the Battery Pack” on page 46.
2. Remove the HDD2 cover. See “Removing the Lower Covers” on page 49.
3. Remove the two securing screws.
4. Use the pull-tab to lift up the HDD module and remove.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.
Step Size Quantity Screw Type
HDD Carrier M2*3 (NL) 2
