Chapter 6 165
Assembly Parts
MIDDLE COVER 42.AR907.001
UPPER CASE W/SPEAKER, FFC, CABLE,TP FOR NON-FP 60.AS307.001
UPPER CASE W/SPEAKER, FFC, CABLE,TP FOR FP 60.AR907.001
LOWER CASE ASSY W/SUB-WOOF,RJ11 W/O TV 60.AR907.002
LOWER CASE ASSY W/SUB-WOOF,RJ11,TV OUT CABLE 60.AS307.002
RAM COVER 42.AR907.002
HDD COVER -1 42.AR907.003
HDD COVER - 2ND 42.AR907.004
DDR BRACKET 33.AR907.001
TP BRACKET 33.AR907.002
ODD CAP 42.AR907.007
VGA SUPPORT BRACKET 33.AHS07.007
MIDDLE COVER TEXTURE TBD
UPPER CASE TEXTURE W/SPEAKER, FFC, CABLE,TP
FOR NON-FP TBD
LOWER CASE ASSY W/SUB-WOOF,RJ11 W/O TV HDMI TBD
OPTICAL BRACKET 33.AR907.003
DVD/CDRW COMBO BEZEL 42.AR907.005
OPTICAL BRACKET 33.AR907.003
ODD BEZEL - SUPER MULTI 42.AGW07.004
OPTICAL BRACKET 33.AR907.003
BD COMBO BEZEL 42.AR907.006
HDD MASTER BRACKET 33.AR907.005
HDD BRACKET ASSY 33.AR907.004
HDD CONNECTOR 20.AR907.001
Category Description Part Number
