Page 86
76
Chapter 3
Removing the Finger Print Reader
1. Remove the Upper Cover. See “Removing the Upper Cover” on page 71.
2. Disconnect the cable as shown.
3. Disconnect the two FFC cables as shown.
4. Remove the four securing screw from the Finger Print Reader board.
Step
Size
Quantity
Screw Type
Launch Board
M2*3 (NL)
4
