Chapter 3
81
Removing the Bluetooth board
1. Remove the Upper Cover. See “Removing the Upper Cover” on page 71.
2. Remove the securing screw from the Bluetooth board.
3. Lift the Bluetooth board away from the main board and disconnect the mainboard cable.
4. Disconnect the cable from the mainboard.
Step
Size
Quantity
Screw Type
Bluetooth Board
M2*3 (NL)
1
