Chapter 3
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Step
Screw
Quantity
Color
Part No.
Switch Cover
M2*3 (NL)
2
MA0000060G0
LCD Module
M2.5*8(NL)
4
MA000005YG0
LCD Module
M2.5*5 (NL)
2
MA000007YG0
Upper Cover
M2.5*8 (NL)
8
MA000005YG0
Upper Cover
M2.5*5 (NL)
7
MA000007YG0
Touch Pad Bracket
M2*3 (NL)
2
MA0000060G0
Launch Board
M2*3 (NL)
2
MA0000060G0
Speaker
M2*3 (NL)
4
MA0000060G0
I/O Board
M2.5*5 (NL)
1
MA000007YG0
Bluetooth Board
M2*3 (NL)
1
MA0000060G0
Modem Module
M2*3 (NL)
2
MA0000060G0
Mainboard
M2.5*5 (NL)
1
MA000007YG0
Thermal Module
M2*6.5
4
MA0000096G0
CPU Fan
M2*4-NI (NL)
3
MACK20040G0
HDMI Module
M2*4-NI (NL)
2
MACK20040G0
