Chapter 3 113
5. Connect the five cables from the mainboard as shown.
IMPORTANT:When removing cables, always hold the cable by the pull-tab or by the connector. Do not hold
the pull by the cable itself to prevent stripping.
Connect A as shown. Connect B as shown.
Connect C as shown. Connect D as shown.
A B
C
D
E
