Chapter 3
83
4. Grasp the Subwoofer Module and lift it up to remove.
Removing the ExpressCard Module
1. See “Removing the Upper Cover” on page 71.
2. Remove the two securing screws.
IMPORTANT:Do not grasp the cable itself to prevent fraying.
3. Disconnect the cable connecting the ExpressCard module.
Step
Size
Quantity
Screw Type
Modem Module
M2*3 (NL)
2
