SEED HAWK ® 2015 TOOLBAR OPERATOR’S MANUAL 16
Tube Size OD
Inches
Nut Size
across flats
Inches
Torque
N•m (lb-ft)
Recommended # Turns
(after finger tightening)
turns (flats)
3/16” 7/16” 8 (6) 1/6 (1)
¼” 9/16” 12 (9) 1/6 (1)
5/16” 5/8” 16 (12) 1/6 (1)
3/8” 11/16” 24 (18) 1/6(1)
½” 7/8” 46 (34) 1/6 (1)
5/8” 1” 62 (46) 1/6 (1)
¾” 1-¼” 102 (75) 1/8 (0.75)
7/8” 1-3/8” 122 (90) 1/8 (0.75)
Description Tire Size
Torque
N•m (lb-ft)
Wing Castor
(Front and Rear)
11 L 15 SL 203 (150)
Main Frame Castor
(Front)
11 L 15 HIGHWAY 203 (150)
Main Frame Castor
(Front)
19.0 / 45 x 17 203 (150)
Rear Axle Tire 500 / 45 x 22.5 271 (200)
Rear Axle Tire 30.5 L 32 SAT (Single) 475 (350)
Rear Axle Tire 30.5 L 32 SAT (Inner Dual) 475 (350)
Rear Axle Tire 30.5 L 32 SAT (Outer Dual) 475 (350)
3.1.3 Flare-Type Tube Fittings
3.1.4 Tire Hub Torque
