SEED HAWK
®
2015 TOOLBAR OPERATOR’S MANUAL 15
3.0 Specifications
ATTENTION! DO NOT use the values in the Bolt Torque Charts if a
different torque value or tightening procedure is given for a specific application.
3.1.1 SAE
3.1.2 Metric
3.1 Hardware Torque
Bolt Diameter
Bolt Torque
Inches
SAE 5
N•m (lb-ft)
SAE 8
N•m (lb-ft)
¼"
11 (8)
16 (12)
5/16"
23 (17)
33 (24)
3/8"
41 (30)
61 (45)
7/16"
68 (50)
95 (70)
½"
110 (80)
155 (115)
9/16"
149 (110)
210 (155)
5/8"
203 (150)
285 (210)
¾"
366 (270)
508 (375)
7/8"
536 (395)
827 (610)
1"
800 (590)
1234 (910)
Bolt Diameter
Bolt Torque
mm
8.8
N•m (lb-ft)
10.9
N•m (lb-ft)
M3
0.5 (0.4)
1.8 (1.3)
M4
3 (2.2)
4.5 (3.3)
M5
6 (4)
9 (7)
M6
10 (7)
15 (11)
M8
25 (18)
35 (26)
M10
50 (37)
70 (52)
M12
90 (66)
125 (92)
M14
140 (103)
200 (148)
M16
225 (166)
310 (229)
M20
435 (324)
610 (450)
M24
750 (555)
1050 (774)
M30
1495 (1103)
2100 (1550)
M36
2600 (1917)
3675 (2710)
