SWITCH WIRING
NOTE: Prior to wiring the status switches to the
controller, determine the correct intended use of
the cable-end reed switch and the motor-end
reed switch. One of these switches will be used
to indicate when the curtain/vent is closed; The
other switch will be used to indicate when the
curtain/vent is open. Which reed switch is
labeled as “closed” or “open” will depend on the
specific application setup of the curtain or vent
to the Power Curtain™. Ensure that the wiring
from the reed switches (motor-end switch and
cable-end switch) to the controller is wired
accordingly.
9. Using the wire nut connectors, wire the cable-end
reed switches to the customer supplied cable. Refer
to Figure 10 for wiring the auxiliary switches to an
Evolution 3000 / 3001. Using a cable tie and cable
tie mount, secure the excess wire to the side of the
cabinet backplate.
10. Wire the motor-end reed switch to customer supplied
cable with the wire nut connectors.
11. The wiring should be routed out through the motor-
end of the PowerCurtain™. Secure excess wire.
CAUTION: Ensure that all wires and cable are secured
and placed so that they do not interfere or
become tangled with the load block, drive, or
motor during complete operation of the
PowerCurtain™.
12. Test and ensure that the PowerCurtain™, controller,
and curtains are operating correctly.
