LE-363 User’s Manual Introduction

1.2

General Specification

Form Factor

3.5 inches embedded motherboard

CPU

Embedded AMD Geode GX533 400MHz
Fanless with heatsink only

Memory

1 x 200-pin DDRSO-DIMM up to 512MB
Unbufferred, none-ECC memory supported only

Chipset

AMD Geode CS5535

USB Port

Two internal USB1.1 ports

BIOS

Phoenix-Award PnP flash BIOS

Green Function

Power saving mode includes doze, standby and suspend modes.
ACPI version 1.0 and APM version 1.2 compliant

Watchdog Timer

System reset programmable watchdog timer

Real Time Clock

Chipset built-in RTC with lithium battery

Enhanced IDE

One Ultra DMA33 IDE interface supports up to 2 ATAPI devices
One 44-pin IDE port onboard

Multi-I/O Port

Chipset WINBOND

W83627HF

Serial Port

One external RS232 and one internal RS232

Parallel Port

One 26-pin internal parallel port

Floppy Port

One slim type Floppy port

IrDA Port

One IrDA compliant Infrared interface supports SIR

K/B & Mouse

External PS/2 keyboard and mouse ports on rear I/O panel

GPIO

One 12-pin Digital I/O connector with 8-bit programmable I/O
interface

Hardware
Monitor

Fan speed, CPU temperature and voltage monitoring

VGA Display Interface

Chipset

AMD Geode GX533 built-in VGA controller with 2D engine

Memory

BIOS selectable up to 4/8/12/16 MB shard with system memory

Display Type

CRT, LCD monitor with analog display
18-bit/24-bit LVDS/24-bit TTL with LCD interface

Connector External

DB15

female connector on rear I/O panel

Onboard 40-pin TTL connector
Onboard 40-pin LVDS connector
Onboard 5-pin backlight inverter connector

Solid State Disk Interface

Compact Flash

1 x Compact Flash Card Type I socket on solder side

DOM

Onboard 44-pin IDE support DOM (Disk On Module)

PCMCIA Card

PCMICA Type I/II slot

Product Specification
