LE-363 User’s Manual Hardware Setup

2.14

The JFRNT provides front control panel of the board, such as power button, reset and

beeper, etc. Please check well before you connecting the cables on the chassis.


Connector: JFRNT
Type: onboard 14-pin (2 x 7) 2.54-pitch header

Function

Signal

PIN

Signal

Function

HDLED 1

2 PWDLED

IDE LED

Active 3

4 N/C

Reset 5

6 GND

Power

LED

Reset

GND 7

8 VCC

N/C 9

10

N/C

PWRBT 11

12

N/C

Power

Button

5VSB 13

14

SPKIN

Speaker

13

1

2

14

JFRNT

Switch and Indicator
