background image

LE-363 User’s Manual I/O Pin Assignment

Appendix A

A.1

Connector: IDE

1

43

Type: 44-pin (22 x 2) box header

44

2

Pin

Description

Pin

Description

1 Reset

2 Ground

3 D7

4 D8

5 D6

6 D9

7 D5

8 D10

9 D4

10 D11

11 D3

12 D12

13 D2

14 D13

15 D1

16 D14

17 D0

18 D15

19 Ground

20 N/C

21 REQ

22 Ground

23 IOW-/STOP

24 Ground

25 IOR-/HDMARDY

26 Ground

27 IORDY/DDMARDY 28 Ground
29 DACK-

30 Ground

31 INT

32 N/C

33 A1

34 N/C

35 A0

36 A2

37 CS0

38 CS1

39 LED2

40 Ground

41 VCC

42 VCC

43 Ground

44 Ground

IDE Port

33
