LE-363 User’s Manual I/O Pin Assignment

A.5

1
2
3
4
5

6
7
8
9


Connector: COM1
Type: 9-pin D-sub male connector on bracket

Pin

Description

Pin

Description

1 DCD

6 DSR

2 RXD

7 RTS

3 TXD

8 CTS

4 DTR

9 -XR

5 Ground

A.6

1

8

Connector: RJ45_1/2
Type: RJ45 connector with LED on bracket

Pin

1

2

3

4

5

6

7

8

Description

TX+

TX-

RX+

RX- N/C

N/C

N/C

N/C

A.7

Connector: PS2
Type: 6-pin Mini-DIN connector on bracket

Pin

1

2

3

4

5

6

Description

KBD MSD

Ground

VCC KBC MSC

3


4

1

2

5

6

Note: The PS/2 connector supports standard PS/2 keyboard directly or both PS/2 keyboard and

mouse through the PS/2 Y-type cable.

A.8 < USB Interface >

9

1

Connector: CN_USB
Type: 10-pin (5 x 2) header for dual USB Ports

2

10

Pin

Description

Pin

Description

1 VCC

2 VCC

3 Data0-

4 Data1-

5 Data0+

6 Data1+

7 Ground

8 Ground

9 Ground

10

NC

IDE Port

35
