LE-363 User’s Manual Hardware Setup

2.3

2.3.1

Connector

Function

Remark

DIMM

Onboard 200-pin DDR SO-DIMM socket

Standard

IDE

44-pin primary IDE connector

Slim

FDD

26-pin slim type floppy connector

Slim

CN_12V

4-pin power supply connector

Standard

CN_AUDIO

5 x 2-pin audio connector

Standard

CDIN

4-pin CD-ROM audio input connector

Standard

CN_DIO

6 x 2-pin digital I/O connector

Standard

CN_USB

5 x 2-pin USB connector

Standard

SYSFAN

3-pin system cooler fan connector

Standard

CN_COM2

5 x 2-pin RS232 serial port

Standard

CN_IR

5-pin IrDA connector

Standard

CF

Compact Flash Type I socket (Solder Side)

Standard

PCMICA

PCMICA Card bus Type I/II slot(Solder Side)

Standard

LPT

26-pin parallel port connector

Standard

CN_TTL

40-pin TTL LCD interface

Standard

CN_LVDS

20-pin LVDS LCD interface

Standard

CN_INV

5-pin LCD backlight inverter connector

Standard

CN_SPWR

4-pin 5V/12V power output connector

Standard

JFRNT

14-pin front panel switch/indicator connector

Standard

2.3.2

Connector

Function

Remark

VGA

DB15 VGA connector

Standard

RJ45_1/2

RJ45 LAN connector

Standard

COM1 Serial

port

connector

Standard

PS2

PS/2 Keyboard/Mouse connector

Standard

DC_IN

DC 12V input jack

Standard

Connector Reference

13
