Integrated Control System 500 2
4. Warranty
One Year Limited Warranty
The ICS-500 is warranted for one year from date of purchase against electrical
and mechanical defects in material and workmanship. If this unit fails to operate
during this period, return it, prepaid to the address below, for repair or
replacement without charge, at the manufacturer's option. Damage by accident
or abuse is not covered by this warranty. This warranty gives you specific rights
which vary from state to state. For claims on this warranty, contact your dealer.
Warrantor: Hired Hand, 1733 Co Rd 68, Bremen, AL 35033.
5. Installation
5.1. Tools Required
Drill Screwdriver
Crimping Pliers Kit Bag (Included)
5.2. Instructions
1. Unpack system, and check that all components are present.
2. Insert two screws into wall approximately 18” apart, leaving the heads away from
the wall.
3. Hang ICS-500 over the two screws. The top two holes in the side flanges are slotted
to allow easy hanging.
4. Finish mounting the unit by securing the sides with eight more screws
5. Make sure all power supplies are disconnected before breaking any wires, or
reaching into the panel.
6. Open ICS-500 panel, and find all connections.
7. Run sensors out to locations inside the house. (One sensor outside the house with
OSC model.) Be sure that the sensors are in a safe location, free from any
temperature influences (direct sunlight, water, etc.)
8. Connect each sensor to its appropriate terminals inside the ICS panel. (See wiring
diagrams in the back of this manual.)
9. Connect wires from staged equipment to the appropriate stage. Be sure to align the
heat/cool switches to the appropriate settings. See wiring diagrams for locations of
terminals.
10. Hookup three wire connection from System 500 board to PVR-H. See wiring
diagrams for locations of terminals.
