Hired-Hand System 500 Programs (Tunnel Model) - Manual (Page 7)

System 500 Power Curtain Controller (Tunnel) Program Sheets Rev 7/98 4801-2973
Program 1,E(met) A B
Stage Mode Sensor(s)Differential Offset Stage Mode Sensor(s)Differential Offset
1 Heat 1 0 2 1 Heat 1 1 1
2 Cool Neg 2 2 1 2 Cool Neg 1 2 1
3 Cool N/T 3 2 2 3 Cool N/T 3 2 2
4 Cool Tun 3 2 4 4 Cool Tun 3 2 4
5 Cool Tun 3 2 4.5 5 Cool Tun 3 2 4.5
6 Cool Tun 3 2 6 6 Cool Tun 3 2 6
7 Cool Tun 3 2 7 7 Cool Tun 3 2 7
8 Cool Tun 3 2 8 8 Cool Tun 3 2 8
Initial Drop 40 Initial Drop 40
Sensor(s) 2 Sensor(s) 3
Degrees above Target 3 Degrees above Target 3
Program 1, F A B
Program 2,0 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 1 3 1 Heat 1 1 3
2 Heat 2 1 3 2 Heat 2 1 3
3 Cool Neg 1 1 1 3 Cool Neg 1 1 1
4 Cool N/T 2 1 1 4 Cool N/T 2 1 1
5 Cool Tun 3 1 1 5 Cool Tun 3 1 1
6 Cool Tun 3 1 3 6 Cool Tun 3 1 3
7 Cool Tun 3 5 5 7 Cool Tun 3 5 5
8 Cool Tun 3 7 8 8 Cool Tun 3 7 8
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 2,1 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 3 1 1 1 Cool Neg 3 1 1
2 Cool Tun 3 1 1 2 Cool Tun 3 1 1
3 Cool Tun 3 2 1 3 Cool Tun 3 2 1
4 Cool Tun 3 3 1 4 Cool Tun 3 3 1
5 Cool Tun 3 4 2 5 Cool Tun 3 4 2
6 Cool Tun 3 5 2 6 Cool Tun 3 5 2
7 Cool Tun 3 6 2 7 Cool Tun 3 6 2
8 Cool Tun 3 7 2 8 Cool Tun 3 7 2
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 4 Degrees Above Target 4
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 3 1 1 1 Cool Neg 3 1 1
2 Cool Tun 3 1 1 2 Cool Tun 3 1 1
3 Cool Tun 3 2 2 3 Cool Tun 3 2 2
4 Cool Tun 3 2 3 4 Cool Tun 3 2 3
5 Cool Tun 3 2 4 5 Cool Tun 3 2 4
6 Cool Tun 3 2 5 6 Cool Tun 3 2 5
7 Cool Tun 3 2 6 7 Cool Tun 3 2 6
8 Cool Tun 3 2 7 8 Cool Tun 3 2 7
Initial Drop 40 Initial Drop 40
Sensors 1&2 Sensors 1&2
Degrees Above Target 4 Degrees Above Target 4
