Hired-Hand System 500 Programs (Tunnel Model) - Manual (Page 6)

System 500 Power Curtain Controller (Tunnel) Program Sheets Rev 7/98 4801-2973
Program 1,8 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 1 2 2 1 Cool Neg 1 2 2
2 Cool Neg 2 20 20 2 Cool Neg 3 2 3
3 Cool Tun 3 20 20 3 Cool Tun 3 2 2
4 Cool Tun 3 20 20 4 Cool Tun 3 2 4
5 Cool Tun 3 20 20 5 Cool Tun 3 2 7
6 Cool Tun 3 20 20 6 Cool Tun 3 2 10
7 Cool Tun 3 20 20 7 Cool Tun 3 3 13
8 Cool Tun 3 20 20 8 Cool Tun 3 3 16
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,9 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 1 2 2 1 Cool Neg 1 2 2
2 Cool Neg 2 20 20 2 Cool Neg 3 2 2
3 Cool Tun 3 20 20 3 Cool Tun 3 2 2
4 Cool Tun 3 20 20 4 Cool Tun 3 2 4
5 Cool Tun 3 20 20 5 Cool Tun 3 2 6
6 Cool Tun 3 30 20 6 Cool Tun 3 0 8
7 Cool Tun 3 30 20 7 Cool Tun 3 3 10
8 Cool Tun 3 20 20 8 Cool Tun 3 2 5
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 CS 1,2 1 0 1 CS 1,2 1 0
2 CS 1,2 1 1 2 CS 1,2 1 1
3 CS 1,2 20 40 3 CS 1,2 1 2
4 CS 1,2 20 40 4 CS 1,2 2 4
5 CS 1,2 20 40 5 CS 1,2 2 7
6 CS 1,2 20 40 6 CS 1,2 2 10
7 CS 1,2 20 40 7 CS 1,2 2 13
8 CS 1,2 20 40 8 CS 1,2 2 16
Initial Drop 4 Initial Drop 4
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,C
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 1,2 0 1 1 CoolNeg 1,2 0 1
2 Cool Neg 1,2 1 1 2 CoolNeg 1,2 1 1
3 Cool Tun 1,2 40 20 3 Cool Tun 1,2 2 1
4 Cool Tun 1,2 40 20 4 Cool Tun 1,2 4 2
5 Cool Tun 1,2 40 20 5 Cool Tun 1,2 7 2
6 Cool Tun 1,2 40 20 6 Cool Tun 1,2 10 2
7 Cool Tun 1,2 40 20 7 Cool Tun 1,2 13 2
8 Cool Tun 1,2 40 20 8 Cool Tun 1,2 16 2
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,d A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 1 2 1 Heat 1 2 2
2 Cool Neg 1 1 1 2 Cool Neg 1 1 1
3 Cool N/T 3 2 2 3 Cool N/T 1 1 2
4 Cool Tun 3 2 4 4 Cool Tun 3 2 3
5 Cool Tun 3 2 6 5 Cool Tun 3 2 4
6 Cool Tun 3 2 8 6 Cool Tun 3 2 5
7 Cool Tun 3 2 10 7 Cool Tun 3 2 6
8 Cool Tun 3 2 12 8 Cool Tun 3 2 8
Initial Drop 40 Initial Drop 40
Sensor(s) 1 Sensor(s) 1
Degrees above Target 2 Degrees above Target 2
