Hired-Hand System 500 Programs (Tunnel Model) - Manual (Page 5)

System 500 Power Curtain Controller (Tunnel) Program Sheets Rev 7/98 4801-2973
Program 1,3 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 1 2 1 Heat 1 2 2
2 Cool Neg 1 1 2 2 Cool Neg 3 1 1
3 Cool N/T 3 20 40 3 Cool N/T 3 20 20
4 Cool Tun 3 20 40 4 Cool Tun 3 0 0
5 Cool Tun 3 20 40 5 Cool Tun 3 2 3
6 Cool Tun 3 20 40 6 Cool Tun 3 2 5
7 Cool Tun 3 20 40 7 Cool Tun 3 2 7
8 Cool Tun 3 20 40 8 Cool Tun 3 2 9
Initial Drop 40 Initial Drop 40
Sensors 1 Sensors 3
Degrees Above Target 4 Degrees Above Target 40
Program 1,4 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 1 1 1 Heat 2 1 1
2 Cool Tun 1 1 1 2 Cool Tun 2 1 1
3 Cool Tun 1 2 2 3 Cool Tun 2 2 2
4 Cool Tun 1 3 4 4 Cool Tun 2 3 4
5 Cool Tun 1 2 7 5 Cool Tun 2 2 7
6 Cool Tun 1 2 9 6 Cool Tun 2 2 9
7 Cool Tun 1 3 1 7 Cool Tun 2 3 1
8 Cool Tun 1 4 1 8 Cool Tun 2 4 1
Initial Drop 40 Initial Drop 40
Sensors 1 Sensors 1
Degrees Above Target 3 Degrees Above Target 3
Program 1,5 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Stir 3 1 0 1 Cool Stir 3 10 10
2 Cool Stir 3 2 1 2 Cool Stir 3 10 10
3 Cool Stir 3 1 0 3 Cool Stir 3 10 10
4 Cool Stir 3 2 8 4 Cool Stir 3 0.2 0
5 Cool Stir 3 2 10 5 Cool Stir 3 1 1
6 Cool Stir 3 2 12 6 Cool Stir 3 2 2
7 Cool Stir 3 2 14 7 Cool Stir 3 3 3
8 Cool Stir 3 2 16 8 Cool Stir 3 4 4
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,6 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 3 2 0 1 Heat 3 2 4
2 Cool Stir 3 1 9 2 Cool Stir 3 1 9
3 Cool Stir 3 1 14 3 Cool Stir 3 1 14
4 Cool Stir 3 1 16 4 Cool Stir 3 1 16
5 Cool Tun 3 1 1 5 Cool Tun 3 0 1
6 Cool Tun 3 1 2 6 Cool Tun 3 1 2
7 Cool Tun 3 1 4 7 Cool Tun 3 2 3
8 Cool Tun 3 1 8 8 Cool Tun 3 3 4
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 6 Degrees Above Target 3
Program 1,7 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 3 1 1 1 Heat 1 1 1
2 Cool N/T 3 1 1 2 Cool N/T 1 1 1
3 Cool N/T 3 2 2 3 Cool N/T 1 2 2
4 Cool Tun 3 3 4 4 Cool Tun 3 3 4
5 Cool Tun 3 2 7 5 Cool Tun 3 2 7
6 Cool Tun 3 2 9 6 Cool Tun 3 2 9
7 Cool Tun 3 3 10 7 Cool Tun 3 3 10
8 Cool Tun 3 4 10 8 Cool Tun 3 4 10
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 1
Degrees Above Target 3 Degrees Above Target 3
