Hired-Hand System 500 Programs (Tunnel Model) - Manual (Page 4)

System 500 Power Curtain Controller (Tunnel) Program Sheets Rev 7/98 4801-2973
Program 0,E A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 1 2 2 1 Cool Neg 1 2 2
2 Cool Neg 2 20 20 2 Cool Neg 3 2 2
3 Cool Tun 3 20 20 3 Cool Tun 3 2 2
4 Cool Tun 3 20 20 4 Cool Tun 3 4 2
5 Cool Tun 3 20 20 5 Cool Tun 3 6 2
6 Cool Tun 3 20 30 6 Cool Tun 3 8 3
7 Cool Tun 3 20 30 7 Cool Tun 3 10 3
8 Cool Tun 3 20 20 8 Cool Tun 3 5 2
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 0,F A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Cool Neg 1 1 2 1 Cool Neg 1 1 2
2 Cool Neg 2 1 2 2 Cool Neg 2 1 2
3 Cool N/T 3 1 1 3 Cool N/T 3 1 1
4 Cool Tun 3 3 3 4 Cool Tun 3 3 3
5 Cool Tun 3 2 2 5 Cool Tun 3 2 2
6 Cool Tun 3 2 4 6 Cool Tun 3 2 4
7 Cool Tun 3 2 6 7 Cool Tun 3 2 6
8 Cool Tun 3 2 9 8 Cool Tun 3 2 9
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,0 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 2 1 1 Heat 3 2 1
2 Cool Stir 1 0 0 2 Cool Stir 3 3 3
3 Cool Neg 1 1 1 3 Cool Neg 3 1 1
4 Cool Tun 3 20 40 4 Cool Tun 3 4 4
5 Cool N/T 1 3 2 5 Cool N/T 3 4 4
6 Cool Tun 3 20 40 6 Cool Tun 3 4 6
7 Cool Tun 3 20 40 7 Cool Tun 3 4 8
8 Cool Tun 3 20 40 8 Cool Tun 3 4 10
Initial Drop 40 Initial Drop 40
Sensors 1 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
Program 1,1 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 3 2 1 1 Cool Tun 2 4 9
2 Cool Neg 3 2 1 2 Cool Neg 3 1 2
3 Cool Neg 3 2 3 3 Cool Neg 3 2 3
4 Cool Neg 3 3 4 4 Cool Neg 3 3 4
5 Cool Tun 2 2 1 5 Cool Tun 2 1 2
6 Cool N/T 2 4 2 6 Cool N/T 2 2 4
7 Cool Tun 2 3 4 7 Cool Tun 2 4 8
8 Cool Tun 2 4 5 8 Cool Tun 2 5 10
Initial Drop 40 Initial Drop 40
Sensors 3 Sensors 3
Degrees Above Target 8 Degrees Above Target 8
Program 1,2 A B
Stage Mode Sensor(s) Differential Offset Stage Mode Sensor(s) Differential Offset
1 Heat 1 2 2 1 Heat 1 2 2
2 Cool N/T 1 1 1 2 Cool N/T 3 8 7
3 Cool Tun 3 20 40 3 Cool Tun 3 2 1
4 Cool Tun 3 20 40 4 Cool Tun 3 3 2
5 Cool Tun 3 20 40 5 Cool Tun 3 4 3
6 Cool Tun 3 20 40 6 Cool Tun 3 6 5
7 Cool Tun 3 20 40 7 Cool Tun 3 7 6
8 Cool Tun 3 20 40 8 Cool Tun 3 5 4
Initial Drop 80 Initial Drop 80
Sensors 1 Sensors 3
Degrees Above Target 3 Degrees Above Target 3
